Drift scanner

Route: /drift

Scenario: You shipped a refactor last Friday. It’s Monday and two users have reported the Settings page is blank. You suspect a route or component broke silently. You run the drift scanner and in 45 seconds it shows you exactly what changed between your last contract snapshot and what’s live right now.

The drift scanner compares your live app against the contract snapshot the SDK took when it last crawled your routes and components. Anything that’s missing, changed, or new shows up as a finding — before users report it.

When to run it

After every deploy — especially refactors, route changes, or component renames.
Before a PDCA iteration — confirm there’s no pre-existing regression before the autonomous loop starts.
When reports spike — users reporting broken pages often correlates with a drift finding you haven’t seen yet.
Weekly — as a background health check even between deploys.

Tab: Scanner

This is where you trigger a scan. Enter the Max paths to walk (10–1000 — start with 50 for a fast check, 500 for a thorough audit) and click Run scan.

The scan typically takes 30–90 seconds. When it completes, results show:

Findings discovered — how many drift items were detected
New findings stored — how many are new since the last scan
Snapshot ID — the ID of the baseline contract used for comparison

If the scan fails

Error banners show a specific code — not a generic 500:

Error code	What it means	What to do
`BUILDER_FAILED`	The scanner couldn’t fetch or parse your app	Check the target URL is publicly reachable, returns valid HTML, and doesn’t redirect to a login page
`SNAPSHOT_MISSING`	No baseline contract exists for this project	Run a full SDK crawl first via the Inventory page
`UPSTREAM_ERROR`	Unexpected error in the diff engine	Check Supabase edge function logs; retry in a few minutes

A Retry button appears immediately after any error.

Tab: Findings

Your list of detected drift items. The three stat cards at the top tell you the overall picture: Open, Critical, Warn counts.

Each finding row shows:

Severity — critical (broken) or medium/low (changed or new)
Surface — route, component, or endpoint
Path — which route or component
Message — what specifically changed (e.g. “Expected /settings/security — not found in live crawl”)

Click View on any row to open the detail drawer with:

The full Expected vs Actual JSON diff — the exact values that changed
→ Lesson button (critical findings only) — promotes this finding directly to a candidate lesson so the pattern is encoded into future fix runs
Dismiss button — mark as a known/intentional change that isn’t a bug

What to do with a critical finding

Click View → read the Expected vs Actual diff.
Is this intentional (you renamed the route on purpose)? → Dismiss.
Is this a regression? → Click → Lesson to create a candidate, then go to Fix orchestrator → dispatch a fix directly.

Tab: Snapshots

A history of contract snapshots — each with its ID, edge count, and timestamp. Use this to see when the baseline was last updated. If the snapshot is months old, your findings might be flagging intentional changes made since then.

To refresh the baseline: run a new full SDK crawl from the Inventory page, then re-scan.

Common tasks

Post-deploy check (the fast path)

Open the Scanner tab.
Set max paths to 50. Click Run scan.
Tab to Findings. No critical findings? Green light.
Critical findings? Click View → check Expected vs Actual → decide: dismiss or fix.

Investigating a user-reported blank page

Run a scan with max paths 500 (thorough).
In Findings, filter to critical severity.
Look for MISSING_ROUTE findings that match the page users reported.
If found: confirm the route was removed unintentionally → dispatch a fix.

Keeping the baseline current

After major route additions:

Trigger a new SDK crawl from Inventory.
Run a drift scan immediately after — the new routes should show 0 findings.
If findings appear for your new routes, the snapshot didn’t update correctly — check the SDK crawl logs.

API


POST /v1/admin/drift/scan             { "project_id": "<pid>", "max_paths": 50 }
GET  /v1/admin/drift?project_id=<pid>&limit=100
GET  /v1/admin/drift/snapshots?project_id=<pid>
PATCH /v1/admin/drift/<id>            { "status": "dismissed" }
POST  /v1/admin/drift/<id>/create-lesson
