Storage

Route: /storage

The Storage page configures where Mushi writes report attachments, session recordings, and evidence artifacts. By default, Mushi uses managed Supabase storage. You can switch to your own bucket for data-residency or cost reasons.

Providers

Provider	Notes
Supabase (default)	Managed — no configuration required. Files stored in your Supabase project.
AWS S3	Requires `bucket`, `region`, and an IAM key pair with `s3:PutObject` / `s3:GetObject`.
Cloudflare R2	Requires `bucket`, `region` (use `auto`), and an R2 API token.
Google Cloud Storage	Requires `bucket` and a service-account JSON key.

Configuring a custom bucket

Each project has its own storage config card. The card shows:

Health status chip — unknown, healthy, degraded, or failing with last-check time
Last health error if the previous check failed
Debug log — a toggle that reveals a per-step test table (step name, ok/fail, ms, detail)

To configure:

Choose a Provider from the dropdown.
Fill in the required fields for your provider (see table below).
Click Save (saves without activating) or Save & enable (saves and marks the config active).
Click Health check to confirm Mushi can reach the bucket — the debug log opens automatically.

Field	Required for
Bucket	S3, R2, GCS, MinIO
Region	S3 (`us-east-1`), R2 (`auto`)
Endpoint	MinIO, custom S3-compatible
Path prefix	All providers (optional subfolder)
Signed URL TTL	All providers (seconds, default 3600)
Access key Vault ref	S3, R2, MinIO — Vault secret name
Secret key Vault ref	S3, R2, MinIO — Vault secret name
GCS service-account Vault ref	GCS — Vault secret name
KMS Key ID	Optional server-side encryption
Use signed URLs	Checkbox
Require encryption	Checkbox

Bucket and region are required for S3 and R2. The API will return a 400 VALIDATION_ERROR if either is empty — this is enforced on the server to prevent saving a broken config.

Storage settings are per-project. Different projects can use different providers.

Required IAM permissions (S3)


{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Action": ["s3:PutObject", "s3:GetObject", "s3:DeleteObject", "s3:ListBucket"],
      "Resource": ["arn:aws:s3:::YOUR_BUCKET", "arn:aws:s3:::YOUR_BUCKET/*"]
    }
  ]
}

Required R2 permissions

Create an R2 API token with Object Read & Write scope scoped to the target bucket.

Required GCS permissions

Attach the roles/storage.objectAdmin role to your service account, scoped to the bucket.

Data residency

For data-residency requirements, use a bucket in the same region as your Supabase instance. See Security → Data residency for the full matrix.
