Integration health
Route: /health
The health page is your observatory for everything that runs in the background: LLM pipelines, cron jobs, and live provider connectivity. Use it to catch degradation before it surfaces as a user-facing bug.
Time window
Use the 1h / 24h / 7d toggle at the top right to scope all stats and charts to a
time window. The window is persisted in the URL (?window=).
LLM health summary
The top section shows aggregate stats across all LLM-touching pipelines for the selected window:
| Stat | Description |
|---|---|
| Total calls | Number of llm_invocations rows in window |
| Fallback rate | % of calls that used a fallback model |
| Error rate | % of calls that returned an error |
| Latency p50 / p95 | Median and 95th-percentile response time |
Below the summary, a per-function breakdown table shows calls, avg/p95 latency, cost
(USD), fallback count, errors, and last failure time for each edge function
(fix-worker, classify-report, judge-batch, pdca-runner, etc.).
A per-model breakdown table shows calls, token count, and errors for each LLM model in use.
Provider probes
Two cards show live connectivity to your BYOK providers:
| Provider | What’s tested |
|---|---|
| Anthropic | POST /v1/messages — confirms key validity and model access |
| OpenAI | POST /v1/chat/completions with max_completion_tokens: 10 — returns ok / degraded / error |
Each card shows: status badge, latency, and last probed time. Click Probe now to run a live round-trip test on demand.
The OpenAI probe uses max_completion_tokens: 10 (not max_tokens) to be compatible
with gpt-5.4-mini and newer models. A degraded status with a short message is normal
and means the key works.
Cron job health
Cards for each background cron job — judge-batch, intelligence-report,
data-retention — show:
- Last run timestamp and staleness indicator
- Run count in window
- Success rate percentage
- Avg duration
Click Trigger now to run a job immediately without waiting for its schedule.
Recent LLM calls log
The bottom of the page lists the most recent llm_invocations rows for this project,
with columns: timestamp, function name, model, fallback badge, error badge, key source,
latency, token count, and links to the source report and Langfuse trace.
Use the Show filter (all / errors / fallbacks) to isolate problem calls. The URL
param ?recent= persists the filter. The list auto-updates via a realtime subscription.
Recommended actions
A banner at the top computes a severity level (ok / warn / urgent) based on the
count of red and amber signals across the page. If the system is healthy, the banner
shows a success tone and can be dismissed.
