Bug clusters (knowledge graph)
Route: /graph (sidebar: Bug clusters, under Bugs; the page was called Knowledge graph before)
The Bug clusters page draws the Mushi Mushi knowledge graph for your project: bug groups, the components and pages they hit, and the fixes made for them. It is the quickest way to see which bugs share a cause, so one fix can close several reports.
The page has three tabs:
| Tab | What it shows |
|---|---|
| Overview | A status banner, a summary of the most fragile areas, and how the map relates to Reports and Inventory |
| Explore | The map itself, as a Graph, a Surface (inventory overlay) or a Table |
| Backend | Apache AGE sync status, ontology tags and node groups, for debugging |
Node types
| Node | What it is |
|---|---|
| Report group | A group of similar reports |
| Component | A component reports were classified against |
| Page | A page reports came from |
| Version / App | The app and the version a report came from |
| Page (inventory), Element, Action | Nodes from your inventory.yaml |
| API, Database | Backend dependencies from the inventory |
| Test, User story | Tests and user stories from the inventory |
Edges carry a type such as causes, related_to, regression_of, duplicate_of,
affects, fix_attempted, fix_applied, fix_verified, and the inventory edges
contains, triggers, calls, reads, writes, reports_against and errors_on.
The filters let you narrow both lists. Nodes with no links are hidden, and the canvas
says how many.
Blast radius
Click any node (or focus it with Tab and press Enter or Space) to load its blast radius: every node it can affect through the graph. The canvas dims everything else, and the side panel lists the affected nodes along with the node’s occurrences and when it was first and last seen.
Surface view
Choose Surface on the Explore tab to overlay your inventory.yaml on the bug graph:
user stories, inventory pages, elements, actions, API and database dependencies, tests
and apps, together with report groups.
Surface needs at least one accepted inventory.yaml proposal. See
User stories · Inventory for how to generate one.
Backend tab
The graph is stored in SQL tables and can be mirrored into the Apache AGE Postgres extension. The Graph backend card shows the backend mode (SQL only, SQL + AGE (dual-write) or AGE only), whether the AGE extension is installed, how many nodes and edges are not yet mirrored, and when the last drift audit ran.
There is no Cypher query console in the console. To query the graph by hand, use the
SQL query page (graph_nodes, graph_edges), or ask a blast-radius
question there in plain English.
API
GET /v1/admin/graph/stats
GET /v1/admin/graph/nodes
GET /v1/admin/graph/edges
GET /v1/admin/graph/blast-radius/:nodeIdSee also
- Concepts → Knowledge graph: the data model behind the graph.
- User stories · Inventory: the inventory that Surface overlays.
- Bugs: open the detail view for any report.
